Menu  Please refer to page 13, “Menu” of “Control panel”.

Source  Select Analog RGB, Analog Y Pb Pr, Digital RGB,

Composite Video, S-Video and Component Video

signals in sequence.

Blank  Convert the image into blank and fully blue. Press again

to restore.

Auto  Press this key to adjust the phase and frequency

automatically.

Pg.Up  In remote control mode, press this key to zoom in the

image (*).

 When the mouse is in use, press this key to turn to the

previous page.

Pg.Dn  In remote control mode, press this key to zoom out the

image (*).

 When the mouse is in use, press this key to turn to next

page.

Press this key and then left/right arrow keys for keystone.

 Press  key to reduce the length of the lower screen.

 Press  to reduce the length of the upper screen.

(*)

   In the remote control mode, the function of these keys is

the same as the up/down/left/right keys on the panel (*).

 In the remote-control mouse mode, the function of these

keys is the same as the up/down/left/right key of the

mouse.

* Press the Auto key to return to previous setup.
